TV-5 Tumbler

Polishing metal and plastic parts

TV-5 Tumbler

As low as $127.25
  • Deburring metal stampings and machined parts
  • Descaling metal castings
  • Cutting radii on sharp edges of metal parts
  • Polishing metal and plastic parts
  • Favorite of hobbyists- holds up to 25 rings
  • May also be used commercially
  • Comes in 115V (Domestic) & 230V (International)
  • Use for deburring of metal stampings and machined parts
  • Descales metal casting
  • CE CERTIFIED
  • Rated Horsepower: 115v-0.07 and 230v-0.05
Replacement parts may be ordered or you may contact Customer Service for a factory repair quote and RMA number

CLICK HERE FOR REPLACEMENT PARTS FOR TV-5

Please be certain you have selected the correct voltage for your location. United States typically uses 115V.

Categories: ,
In stock
SKU
TV-5 Tumbler

Your new Raytech Tumbler comes with a motorized base, one bowl and one lid. If the tumbler will be used for polishing as well as for cutting, always reserve one bowl strictly for the polishing step so that it will be free from embedded cutting grit. The working capacity of the Tumble-Vibe5 is approximately.05cu.ft. (or three pints) or 4 pounds. The capacity includes both the media and the work pieces. This popular economical and versatile unit is a favorite of hobbyists and is used commercially as well. The .05 cubic foot 8-inch bowl with solid lid holds 25 ring castings with media or will process about four pounds of rock. Do not run steel shot in this machine . Doing so will void the warranty. CE



Shipping weight 7 pounds, Shipping Volume 1.05 Cubic feet , 11 x 11 x 14”

Tech Tips

This popular economical and versatile unit is a favorite of hobbyists and is used commercially as well. The .05 cubic foot 8-inch bowl with solid lid holds 25 ring castings with media or will process about four pounds of rocks.



Before
After




WARNING: This product can expose you to lead, which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov

More Information
Part Number 23001R ( 115V ) and 24106R ( 230V)
Motor 115v 60Hz 0.9 Amps Wattage Power 50W / 230v is 50Hz 0.5 Amps Wattage Power 40W Noise level 82db
Best Use Deburring metal stampings and machined parts
Helpful Hint See Tech Tips
Unit Weight 7lbs
Pack Carton Size 1.05 Cubic feet
Box Measurements 11 x 11 x 14”
Bowl Capacity Size .05 Cubic ft holding 3 pints or 4 pounds (inclusive of media and work pieces)
Bowl Diameter 8 Inches
Bowl Height To Lid 3.75 Inches
Bowl Width To Shaft 4 Inches
